Design

• Capacity: 10 to 360 m³/min

• Total head: 1.5 to 20 m

• Liquid temp.: 0 to 40°C

• Max. allw. subm.: 25 m

Construction

• Impeller: Axial flow, Mixed flow

• Shaft seal:
  Cartridge type, duplex mechanical seals in tandem arrangement

  • Upper: carbon/ceramic

  • Lower: silicon carbide/silicon carbide

• Bearing: Grease lubricated ball bearing

• Driver: Air-filled water tight electric motor

• Mounting method: Sole plate with rotation stopper

Accessories

• 10 m water tight rubber insulated flexible cable

• Cable glands for each cable

• Built-in winding temp. detectors for each phase

• Built-in float type leakage detector

Codes & Standards

• JIS, JEC, JEM

OPTION

• Design: Bigger capacity, higher total head, etc.

• Construction:

  • Adjustable pitch impeller

  • carbon/silicon carbide

  • tungsten carbide/tungsten carbide

  • Explosion proof motor

• Accessories:

  • Longer cable

  • Column pipe, anchor bolts

  • Thrust bearing temp. detector
